Sealey DJ01 - Edge to Surface Jointing

5.3. EDGE TO SURFACE JOINTING (g.3, g.4)
5.3.1.  Markcentrelineofdowelxingsinsurfaceboardandplaceinpositionontheworkbench(g.3).
5.3.2.  Laypre-drillededgeboardinpositionontopofsurfaceboard(g.3)ensuringalignmentofedges.Placeedgeboardbyadjustingits
 positionsuchthatthecentrelineofthedowelholesisdeadcentretotherelevantguidebush(g.4)Clampinplaceusingclampblock.
NOTE: Use additional clamping if required.
5.3.3.  Locatethejigontheprotrudingdowels(g.4)usingtherelevantslotfortheguidebushbeingused.  
5.3.4.  Selectdowelsizeandrelevantdrillbit.Setthedepthgaugeonthedrillbittoensuresu󰀩cientholedepthtopreventthedowelfrom
bottoming out on jointing thus preventing the boards from fully meeting.
5.3.5.  Tocontinuedrillingfurtherholes,loosenthedrilljigclampsandcarefullyslidethedrilljigtoit’snewposition.TIP: Spacing can be
achieved by placing a dowel into an existing hole and using a spacer-block between this and the drill jig to set the new location.
IMPORTANT: When moving the drill jig location at least one set of clamps must be holding the board in position to prevent movement
and misalignment of the dowels.
Original Language Version
© Jack Sealey Limited
DJ01 Issue 1 24/01/18
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
fig.
3
fig.
4
