257If and when
Fuse assignment
This list shows the fuses which can be replaced relatively
easily by the owner.
No. Consumer Amps
1 Air conditioner 10
2 Footwell lamps 5
3 Heated washer jets 5
4 Radiator fan 5
5 Parking aid, automatic gearbox 10
6 Air conditioner (air purity sensor), pressure sensor 5
7
Electronic Stability Programme (ESP), brake light
switch, clutch pedal switch, steering angle sensor
10
8 Telephone 5
9 Vacant
10 Adaptive headlights right 5
11
Airbag and disconnection of the front passenger air-
bag
5
12 Diagnostic socket 10
13 Steering column unit 10
14 Brake lights 10
15 Instrument panel 10
16 Vacant
17 Tyre pressure control, rain/light sensor 10
18 Adaptive headlights left 5
19 Vacant
20 Vacant
21 Vacant
22 Driver door / front passenger door 15
23 Rear doors 15
No. Consumer Amps
24 Central electrics unit for convenience equipment 20
25 Heater blower 30
26 Rear window heater 30
27 Power socket for trailer (control unit) 30
28 Fuel pump, auxiliary pump for diesel 20
29 Vacant
30 Sliding/tilting sunroof 20
31
Diagnosis connection, automatic anti-dazzle interior
mirror, reverse light, automatic gearbox
15
32 Towing socket 15
33 Lighter 20
34 Lambda probe heater 10
35 Luggage compartment power socket* 20
36 Wiper system 30
37
Pump for windscreen washer and headlight washer
system
30
38 Luggage compartment illumination, alarm 15
39 Radio, Amplifier 20
40 Horn 25
41 230 volt socket 30
42 Electronic Stability Programme (ESP) 25
43 Engine management 15
44 Seat heating 35
Some of the electrical items listed in the table are only fitted on certain
models or are optional extras.
The electric windows and electric seat adjusters are protected by circuit
breakers. These reset automatically after a few seconds when the overload
(caused for example by frozen windows) has been corrected.
