277If and when
Position of the bulbs
Pos.
⇒ fig. 218
Bulb function
A Reverse light P21W LL
Fitting the bulb holder
The bulb holder is easy to fit.
– Check that the seal is seated correctly on the bulb holder.
– Position the bulb holder on the tail light and align it so that it is
securely seated.
– Press the bulb holder into the tail light until it engages.
– Fit the cover back in the interior trim so that it engages.
– Make sure that all bulbs for the tail lights are working.
Side turn signals
Fig. 219 Side turn signal
– Press the turn signal to the left or to the right to remove the
bulb.
– Remove the bulb holder from the turn signal.
– Remove the failed glass bulb and replace with a new bulb.
– Insert the bulb holder in the turn signal guide until it clicks into
place.
– First place the turn signal in the opening in the bodywork, fixing
the tabs ⇒ fig. 219, arrow
1
.
– Insert the bulb as shown by the arrow
2
⇒ fig. 219.
