267If and when
Fitting the air duct
Once the bulb(s) for the right-side headlight have been
changed, the air duct must be re-installed.
Fig. 200 Air duct on
right side of vehicle
– Place the air duct in the correct position.
– First turn the two screws
A
in lightly, then tighten both screws.
– Push the air duct into guide
B
.
Bi-Xenon AFS headlight bulbs
Fig. 201 Bi-Xenon AFS
headlight bulbs
Turn signal
Xenon headlight (dipped beam/main beam)
A
B
