270 If and when
Removing the tail light
To change the bulbs you must remove the tail light assem-
bly. Removing the light requires a certain degree of practical
skill.
Fig. 206 Luggage com-
partment: Location of the
bolt securing the tail
light unit
Fig. 207 Removing tail
light from side panel
A special retaining screw is used to secure and guide the tail light.
– Check which of the bulbs is defective.
– Open the tailgate.
– Prise open the cover with the flat side of a screwdriver in the
slot ⇒ fig. 206
1
.
– Use a screwdriver to loosen the screw
2
(arrow) located be-
hind the cover.
– Gradually ease the tail light out of the housing (⇒ fig. 207 posi-
tions
3
and
4
) by pulling alternately in positions
1
and
2
.
– Remove the bulb holder ⇒ page 271.
CAUTION
Take care when removing the tail light to make sure there is no damage to
the paintwork or any of its components.
Note
Make sure you have a soft cloth ready to place under the glass on the tail
light, to avoid any scratches.
