Seats and storage compartments 145
Safety First Operating Instructions Practical Tips Technical Specifications
Retaining strap*
The retaining strap can be used to secure items of luggage to
the right-hand side lining in the luggage compartment.
– Hook the retaining strap into housing or ⇒ fig. 119.
You can attach the strap to the top or bottom housing, depending on the size
of the object you wish to secure.
To secure shorter objects, the retaining strap can also be attached to the
centre. However, this is only possible if the strap is attached to housing .
WARNING
The retaining strap should only be used to hold objects weighing up to 5
kg. Heavier objects cannot be safely secured (risk of injury).
Luggage compartment cover*
The cover blocks the view into the luggage compartment.
Pulling out the luggage compartment cover
–Using handle ⇒ fig. 120, pull the rolled-up cover evenly
towards the rear of the vehicle.
– Insert the ends of the bar into the grooves in the left and right-
hand side trim ⇒ fig. 120 -arrows-.
Retracting the luggage compartment cover
– Lift the bar out of the grooves in the side trim.
– Let the cover roll up slowly.
Removing and installing the luggage compartment cover ⇒ page 147
Fig. 119 Retaining strap
attached to right-hand
side lining
A
B
A
B
Fig. 120 Tailgate open
with luggage compart-
ment cover closed
A
