Seats and storage compartments146
WARNING
The luggage compartment cover should not be used as a storage shelf.
Articles placed on this cover could cause injury to vehicle occupants in an
accident or if the brakes are applied suddenly.
Net partition*
The net partition prevents loose objects in the luggage
compartment from being thrown forward into the passenger
compartment (e.g. under sudden braking).
Pulling out and securing the net partition
– Pull the net up as far as it will go.
– Engage the ends of the bar in the retainers ⇒ fig. 121.
Using the net partition with the rear backrest folded down
– Fold down the rear backrests ⇒ page 149.
– Pull the net upwards.
– Engage the ends of the bar in the retainers ⇒ fig. 121.
Retracting the net partition
– Unhook the bar from the retainers.
– Let the net retract slowly.
Removing and installing the net partition ⇒ page 147.
Fig. 121 Retainers for the
net partition
B
A
A
