If and when 283
Safety First Operating Instructions Practical Tips Technical Specifications
Position of the bulbs
Changing bulbs. LED lamps
All bulbs can be changed easily in the bulb holder.
The bulb is secured with a bayonet fastening. The table below gives
an overview of the bulb positions.
– Lightly press the defective bulb into the bulb holder, then turn it
to the left and remove it.
– Fit the new bulb, pressing it into the bulb holder and turn it to the
right as far as it will go.
– Use a cloth to remove any fingerprints from the glass part of the
bulb.
– Check whether the new bulb is working.
– Re-install the bulb holder ⇒ page 283.
Position of the bulbs
Fitting the bulb holder
The bulb holder is easy to fit.
Pos. ⇒ page 282,
fig. 227
Bulb function
A Turn signal
B Brake lights and side lights
Fig. 228 Position of the
bulbs in the bulb holder:
Example: Outer left tail
light
Pos. ⇒ fig. 228 Bulb function
A Turn signal
Fig. 229 Securing the
bulb holder in the tail
light unit
ExeoST_EN.book Seite 283 Freitag, 3. September 2010 11:41 11
