APOLLO 600+
PG 20 TESTED. TRUSTED… WORLDWIDE.
TECHNICAL DATA
Substitute (Alternative) Leakage Test
Nominal Voltages:
Display Range:
Measurement Range
Resolution:
Operating Error:
>25 VAC <50 V
AC
0.00 mA … 19.99 mA
0.20 mA … 19.99 mA
0.01 mA
± 10% +2 digits
Protective Conductor Current (IPE)
Measurement Method
Test Voltage:
Display Range:
Measurement Range:
Resolution:
Operating Error:
Frequency Response:
Differential Leakage Current
Supply Voltage, maximum load current 16 A
0.01 mA … 19.99 mA
0.25 mA … 19.99 mA
0.01 mA
± 5% of reading ±3 digits
40 Hz to 2.5 kHz
Touch Current (IT)
Measurement Method
Test Voltage:
Display Range:
Measurement Range:
Resolution:
Operating Error:
Frequency Range:
Direct Leakage Current
Supply Voltage, maximum load current 16 A
0.00 mA … 5.0 mA
0.10 mA … 5.0 mA
0.01 mA
±5 % of reading ±2 digits
DC to 2.5 kHz
Load Current Measurement
Test Voltage:
Display Range:
Measurement Range:
Resolution:
Operating Error:
Supply Voltage, maximum load current 16 A
0.00 … 16.00 A (0.00 kVA … 4.00 kVA)
0.50 … 16.00 A (0.50 kVA … 4.00 kVA)
0.01 A
±10 % of reading ±5 digits
Continuity (Lead Test)
Test Voltage:
Test:
5 V
DC
nominal
Live / Neutral checks for o/c, s/c
