Chapter 4
6
4 MOUNTING
4.1 Mounting variants
Mounting with locknut
The types SEBAPuls 8 and 15 can be mounted on the SEBA standard boom with opening for thread
G 1
1/2
by means of the locknut. Push the sensor into the opening of the boom and fix it with the
enclosed locknut.
For the distance to the wall, refer to chapter 4.4.
SEBAPuls 8 SEBAPuls 15
mounted to SEBA standard boom mounted to SEBA standard boom
with lock nut with lock nut
SEBA standard boom
