Seca 701 - Technical Data

28
9. Technical data
Maximum load 200 kg
Dimensions scale
width: 292 mm / 11.5 ins
height: 848
+10
mm / 33.4
+0.4
ins
depth: 409 mm / 16.1 ins
Dimensions weighing platform
width: 292 mm / 11.5 ins
height: 75
+10
mm / 2.8
+0.4
ins
depth: 300 mm / 11.8 ins
Height of figures 20 mm
Weight approx. 8,8 kg
Temperature range +10 °C to +40 °C
Batteries 6 type AA 1.5 V batteries
Calibration as per Directive
90/384/EEC approved for medical use, Class III
Medical product as per Directive
93/42/EEC Class I
EN 60 601-1:
Insulated equipment, Protection Class II:
medical electrical equipment type B:
Functions mother-and-baby function, Hold,
Body Mass Index
Graduations
0 up to 150 kg: 0,05 kg
150 up to 200 kg: 0,1 kg
Accuracy at first calibration
to 25 kg: ± 25 g
25 kg to 100 kg: ± 50 g
100 kg to 150 kg: ± 75 g
150 kg to 200 kg: ± 100 g
Minimum load 1 kg
seca 701
Power supply battery / mains unit (option)
seca 7017021904 / -994
Power supply mains unit / battery (option)
