Capacity tables
BD1.4F-AUTO
compressor
22.
CAPACITY TABLES BD1.4F-AUTO
COMPRESSOR
Test conditions EN 12900/CECOMAF ASHRAE LBP
Condensing temperature 55°C 54.4°C
Ambient temperature 32°C 32°C
Suction gas temperature 32°C 32°C
Liquid temperature no subcooling 32°C
Capacity and power consumption tolerance +/-10% at rating point -10/55°C
EN 12900 Household (CECOMAF)
Evap. temp. in °C -25 -23.3 -20 -15 -10 -6.7 -5 0 5
Capacity in W 14.3 17.5 24.3 36.1 50.0 60.5 66.4 85.5 108
Power cons. in W 26.1 27.5 30.3 35.0 40.0 43.4 45.2 50.4 55.6
Current cons. in A 1.98 2.08 2.30 2.65 3.03 3.29 3.42 3.82 4.21
COP in W/W 0.55 0.64 0.80 1.03 1.25 1.39 1.47 1.70 1.94
EN 12900 Household (CECOMAF)
Evap. temp. in °F -13 -10 0 10 14 20 30 40 41
Capacity in W 14.3 17.5 29.3 43.6 50.0 60.6 81.0 105 108
Power cons. in W 26.1 27.5 32.3 37.7 40.0 43.4 49.3 55.0 55.6
Current cons. in A 1.98 2.08 2.45 2.86 3.03 3.29 3.73 4.17 4.21
COP in W/W 0.55 0.64 0.91 1.15 1.25 1.40 1.64 1.91 1.94
ASHRAE LBP
Evap. temp. in °F -13 -10 0 10 14 20 30 40 41
Capacity in BTU/h 61.8 75.1 125 185 212 257 344 446 457
Power cons. in W 26.2 27.5 32.3 37.7 39.9 43.4 49.1 54.8 55.3
Current cons. in A 1.98 2.08 2.45 2.86 3.03 3.28 3.72 4.15 4.19
ERR in BTU/h 2.36 2.73 3.86 4.91 5.32 5.94 7.00 8.15 8.27
ASHRAE LBP
Evap. temp. in °C -25 -23.3 -20 -15 -10 -6.7 -5 0 5
Capacity in W 18.1 22.1 30.5 45.0 62.3 75.3 82.6 106 134
Power cons. in W 26.2 27.5 30.3 35.0 39.9 43.3 45.1 50.3 55.3
Current cons. in A 1.98 2.08 2.30 2.65 3.03 3.28 3.42 3.81 4.19
COP in W/W 0.69 0.80 1.00 1.29 1.56 1.74 1.83 2.12 2.43
