Specifications
2.1 Terminals
GC1100 controller host three types of terminal blocks as shown in Figure 2, Figure 3 and Figure 4 given
below:
10.16 mm pitch connector suitable for 2 sq. mm wire
Figure 2: Connectors of 10.16 mm pitch
Table 2: 10.16 mm pitch connector details
*Phoenix (Phoenix Contact (I) Pvt. Ltd.)
5.08 mm pitch connectors suitable for 2 sq. mm wire
Figure 3: Connectors of 5.08 mm pitch
Table 3: 5.08 mm pitch connectors details
*Phoenix (Phoenix Contact (I) Pvt. Ltd.)
3.5 mm pitch connector suitable for 0.5 – 1.5 sq. mm wire
Figure 4: Connectors of 3.5 mm pitch
