SEDEMAC GC1100 User Manual

GC1100 SEDEMAC
Page | 4
Table 4: 3.5 mm pitch connector details
Connector
type
Male (On
controller) *
SM Part
Number
Female
(Mating)*
SM Part
Number
Quantity
(Nos)
4-Pin
5441294
SM0000278
5441430
SM0003731
2
6-Pin
5441317
SM0003346
5449283
SM0003732
1
8-Pin
5441320
SM0003348
5441456
SM0003733
1
10-Pin
5443962
SM0003349
5449306
SM0003734
1
* Phoenix (Phoenix Contact (I) Pvt. Ltd.)
2.2 Power Supply Specifications
Following table gives a brief overview of power supply specifications
Table 5: Power supply specifications
Controller's terminal number
1, 2 (Ground and Battery positive respectively)
Supply voltage range
8 to 32 V-DC (Suitable for 12/24 V-DC system)
Cranking drop out period
50 mS
Maximum reverse voltage
-32 V-DC
Battery voltage measurement
accuracy
±1 % full scale
Battery voltage measurement
resolution
0.1 V
Maximum current
~ 0.2 A @ 12 V-DC (Excluding all current loads for the high side
driver’s output and Rotary Actuator's output)
Standby current
80 mA @ 12 V-DC
Deep sleep current
20 mA @ 12 V-DC
2.3 Generator Voltages and Frequency Measurements
Following table gives a brief overview of generator voltage and frequency measurements
Table 6: Generator voltage and frequency measurements
Controller's terminal number
27, 28, 29, 30 (N, B, Y, R respectively)
Measurement type
True RMS
Phase to Neutral voltage
20 to 350 V-AC RMS
Phase to Phase voltage
20 to 606 V-AC RMS
Voltage accuracy
±1% of full scale for Ph to N
±1.5% of full scale for Ph to Ph
Voltage resolution
1 V-AC RMS for Phase to Neutral
2 V-AC RMS for Phase to Phase
Frequency range
5 to 75 Hz
Frequency accuracy
Accuracy: 0.25% of full scale
Resolution: 0.1 Hz
