SEDEMAC GC1100 - Digital Input Source Selection

GC1100 SEDEMAC
Page | 31
6
Water Level Switch (Low Water LVL Switch)
7
Emergency Stop
8
Remote Start / Stop
9
Simulate Start
10
Simulate Stop
11
Simulate Auto
12
Close Generator/Open Mains Switch (Close Gen/Opn Mains Swch)
13
Close Mains/Open Generator Switch (Close Mains/Opn Gen Swch)
14
Simulate Mains
15
Reserved
16
V-Belt Broken Switch
Table 22: Engine temperature sensor calibration
Resistance (Ω)
Temperature° C
0 – 1000 (R1-R10)
25 – 300 °C (T1-T10)
Table 23: Fuel level sensor calibration
Resistance (Ω)
Fuel level (%)
0 – 1000 (R1-R10)
0 – 100 % (L1-L10)
Table 24: LOP sensor calibration
Resistance (Ω)
Pressure (Bar)
0 – 1000 (R1-R10)
0.0 – 10.0 Bar (V1-V10)
Table 25: LOP sensor (4-20mA) calibration
Current (mA)
Pressure (Bar)
4 – 20 (I1-I10)
0.0 – 10.0 Bar (V1-V10)
7.3 Digital Output Source Selection
Following table gives a brief overview of selection criteria for digital output source
Table 26: Digital output source selection
#
Output source (On screen)
1
Disable
2
Sounder Alarm
3
Battery Over Volt
4
Battery Under Volt
5
Charge Alt Shutdown
6
Charge Alt Warning
7
Close Genset Contactor (Close Gen Contactor)
8
Close Mains Contactor
9
Mains Failure
10
Common Alarm
11
Common Electric Trip
12
Common Shutdown
