SEDEMAC GC1100 User Manual

GC1100 SEDEMAC
Page | 32
#
Output source (On screen)
13
Common Warning
14
Cooling Down
15
Digital Input A (Dig In A)
16
Digital Input B (Dig In B)
17
Digital Input C (Dig In C)
18
Digital Input D (Dig In D)
19
Digital Input E ((Dig In E)
20
Digital Input F (Dig In F (Anlg In LOP 1))
21
Digital Input G (Dig In G (Anlg In Eng Temp))
22
Digital Input H (Dig In H (Anlg In Fuel LVL))
23
Digital Input I (Dig In I (Anlg In LOP 2))
24
Emergency Stop
25
Stop Solenoid
26
Fail To Start
27
Fail To Stop
28
Fuel Relay
29
Generator Available (Gen Available)
30
R Phase Over Voltage Shutdown (R Phase OV Shutdown)
31
R Phase Under Voltage Shutdown (R Phase UV Shutdown)
32
Y Phase Over Voltage Shutdown (Y Phase OV Shutdown)
33
Y Phase Under Voltage Shutdown (Y Phase UV Shutdown)
34
B Phase Over Voltage Shutdown (B Phase OV Shutdown)
35
B Phase Under Voltage Shutdown (B Phase UV Shutdown)
36
Generator Over Current (Gen Over Current)
37
High Engine Temp
38
Low Fuel Level (Low Fuel LVL)
39
Low Lube Oil Pressure (Low LOP)
40
Mains High Voltage (Mains High Volt)
41
Mains Low Voltage (Mains Low Volt)
42
Oil Pressure Open Circuit
43
Open Generator Contactor (Open Gen Contactor)
44
Open Mains Contactor
45
Over Frequency Shutdown (Over Freq Shutdown)
46
Over Speed Shutdown
47
Gross Over Speed Shutdown (Gross Over Spd Shutdown)
48
Start Relay
49
Temp Sensor Open Circuit
50
Under Frequency Shutdown (Under Freq Shutdown)
51
Under Speed Shutdown
52
Maintenance Due
53
Stop Mode
54
Auto Mode
