SEDEMAC GC1100 User Manual

GC1100 SEDEMAC
Page | 13
Terminal
Sr. No.
Name
Description
Phoenix Female
(Mating) Connector
Part No.
13
CAN H
CAN High
14
CAN L
CAN Low
15
RS485_B
RS485 – B
16
RS485_A
RS485 – A
17
Reserved
Reserved
5447560
18
Reserved
Reserved
19
Reserved
Reserved
20
Reserved
Reserved
21
DIG_IN D
Input From Switch – D
22
DIG_IN E
Input From Switch – E
23*
ANLG_I_IN
Analog Input 4-20 mA
24
ANLG_IN ENG_TEMP
Analog Input From Engine
Temperature Sensor
25
ANLG_IN FUEL_LEVEL
Analog Input From Fuel Level
Sensor
26
ANLG_IN LOP
Analog Input From Lube Oil
Pressure Sensor
27
GEN_V–IN NTRL
Voltage Input From Gen Neutral
5453499
28
GEN_V–IN B
Voltage Input From Gen Phase B
29
GEN_V–IN Y
Voltage Input From Gen Phase Y
30
GEN_V–IN R
Voltage Input From Gen Phase R
31
MAINS_V–IN NTRL
Voltage Input From Mains Neutral
5453499
32
MAINS_V–IN B
Voltage Input From Mains Phase B
33
MAINS_V–IN Y
Voltage Input From Mains Phase Y
34
MAINS_V–IN R
Voltage Input From Mains Phase R
35
GEN_CT–IN B1
CT Input 1 From Gen Phase B
5441252
36
GEN_CT–IN B2
CT Input 2 From Gen Phase B
37
GEN_CT–IN Y1
CT Input 1 From Gen Phase Y
38
GEN_CT–IN Y2
CT Input 2 From Gen Phase Y
39
GEN_CT–IN R1
CT Input 1 From Gen Phase R
40
GEN_CT–IN R2
CT Input 2 From Gen Phase R
41
SCP
Sensor Common Point
42
MPU–IN
MPU Input
* the 0-5V (2.5 ± 2V) input for paralleling is not available for the GC1100 variant, as it does not have
e-governing module, which is shown in the print of the back casing.
