GC1100
SEDEMAC
Page | 55
Register
Offset
Page No.
Value for G
C11
00
Scale
Factor
Unit
Bits/ Sign
Auxiliary
input a
E-0001/0001
N-0101/0101
W-0010/001
0
E-0100/0100
S-0011/0011
13/16-16/16
Auxiliary
input b
--
E-0001/0001
N-0101/0101
W-0010/001
0
E-0100/0100
S-0011/0011
9/16-12/16
Auxiliary
input c
--
E-0001/0001
N-0101/0101
W-0010/001
0
E-0100/0100
S-0011/0011
5/16-8/16
Auxiliary
input d
--
E-0001/0001
N-0101/0101
W-0010/001
0
E-0100/0100
S-0011/0011
1/16-4/16
72
Alarm 9
--
Auxiliary
input e
E-0001/0001
N-0101/0101
W-0010/001
0
E-0100/0100
S-0011/0011
13/16-16/16
Auxiliary
input f
--
E-0001/0001
N-0101/0101
W-0010/001
0
E-0100/0100
S-0011/0011
9/16-12/16
Auxiliary
input g
--
E-0001/0001
N-0101/0101
W-0010/001
0
E-0100/0100
S-0011/0011
5/16-8/16
Auxiliary
input h
--
E-0001/0001
N-0101/0101
W-0010/001
0
E-0100/0100
S-0011/0011
1/16-4/16
73
Page 26
Alarm 10
--
Gen L1 phase
low v
olt
E-0001/0001
W-0010/001
0
S-0011/0011
13/16-16/16
Gen L1 phase
high volt
--
E-0001/0001
W-0010/001
0
S-0011/0011
9/16-12/16
Gen L2 phase
low v
olt
--
E-0001/0001
W-0010/001
0
S-0011/0011
5/16-8/16
64
66
Table of Contents
Default Chapter
6
Table of Contents
6
Introduction
11
Key Highlights of the Product
11
Product Features
11
Table 1: Features List
11
Figure 1: GC1100 Genset Controller's Front Fascia
12
Specifications
13
Terminals
13
Figure 2: Connectors of 10.16 MM Pitch
13
Figure 3: Connectors of 5.08 MM Pitch
13
Figure 4: Connectors of 3.5 MM Pitch
13
Table 2: 10.16 MM Pitch Connector Details
13
Table 3: 5.08 MM Pitch Connectors Details
13
Power Supply Specifications
14
Generator Voltages and Frequency Measurements
14
Table 4: 3.5 MM Pitch Connector Details
14
Table 5: Power Supply Specifications
14
Table 6: Generator Voltage and Frequency Measurements
14
Load Current Measurements
15
Mains Voltage and Frequency Measurements
15
Table 7: Load Current Measurements
15
Table 8: Mains Voltage and Frequency Measurements
15
Digital Inputs
16
Analog Resistive Sensor Inputs
16
Figure 5: SCP Connection
16
Table 9: Digital Inputs
16
Table 10: Analog Resistive Sensor Inputs
16
Analog Current Input
17
Magnetic Pick up Input
17
Digital Outputs
17
Table 11: Analog Voltage/Current Input
17
Table 12: Magnetic Pickup Input
17
Table 13: Digital Outputs
17
D+ Chg Alt
18
Sensor Common Point
18
Deep Sleep Mode Feature
18
Table 14: D+ CHG ALT
18
Table 15: Sensor Common Point
18
Communication Ports
19
Table 16: Communication Ports
19
Installation
20
Dimensions
20
Mounting on Panel
20
Figure 6: Dimensions of the GC1100 Genset Controller
20
Figure 7: Fixing Clip and Screw Supplied Along with Controller
21
Figure 8: Controller Mounting on the Panel Using the Fixing Clips
21
Terminal Description
22
Figure 9: GC1100 Genset Controller from Backside
22
Table 17: Details of GC1100 Terminals
22
Typical Wiring Diagram
24
Figure 10: GC1100 Genset Controller Power Circuit (Used in the Auto Mains Failure Mode)
24
Figure 11: GC1100 Genset Controller Control Circuit (Used in the Auto Mains Failure Mode)
25
Module Display
26
Monitoring Mode
26
Table 18: Screens of Engine Status and Operating Mode
26
Description of Control Keys
29
Functions of Control Keys
29
Figure 12: Control Keys Function
29
Table 19: Control Keys in Different Modes
29
Configuration Mode
30
Figure 13: Configuration Mode Screen
30
Figure 14: Configuration Mode Authentication Page Screen
30
Figure 15: Saving Setting Screen
30
List of Configurable Parameters
31
Table 20: Configurable Parameters
31
Digital Input Sources Selection
40
Table 21: Digital Input Sources Selection
40
Digital Output Source Selection
41
Table 22: Engine Temperature Sensor Calibration
41
Table 23: Fuel Level Sensor Calibration
41
Table 24: LOP Sensor Calibration
41
Table 25: LOP Sensor (4-20Ma) Calibration
41
Table 26: Digital Output Source Selection
41
Module Operation
43
Auto Mode
43
Figure 16: SMD for AMF Mode
44
Figure 17: SMD for Auto Exercise Mode
45
Figure 18: SMD for Cyclic Mode
46
Manual Mode
47
Figure 19: SMD for Manual Mode
47
Alarms
48
Table 27: Alarm Actions
48
Table 28: Alarms and Their Causes
48
Troubleshooting
51
Table 29: Common Faults and Their Remedial Actions
51
RS485 MODBUS Based Protocol
53
Connection Details
53
Figure 20: RS485 MODBUS Connection with the Help of Two Core Shielded Twisted Pair Cable
53
Table 30: RS485 MODBUS Communication Configuration Setting
53
Precautions
54
Function Code Used
54
Table 31: Details of Function Codes
54
Table 32: Command from MODBUS Master for Function 4
54
Table 33: Normal Response from Genset Controller Slave for Function 4
54
Table 34: Command from MODBUS Master for Function 16
55
Table 35: Normal Response from Genset Controller Slave for Function 16
55
Table 36: Command from MODBUS Master for Function 3
55
Register Map
56
Table 37: Normal Response from Genset Controller Slave for Function 3
56
Table 38: Register Map for Input Registers
56
Table 39: Register Map for Holding Registers
60
Table 40: Interpretation of Alarm Status Results
60
Introduction to Communication Protocol
53
Protocol for CAN-Based Communication
61
Connection Details
61
Structure of Communication
61
Table 41: Structure of Communication
61
Table 42: Structure of Broadcasted Message
67
Table 43: Structure of Command Message
67
Packet Structure
68
Table 44: Structure of Command Message Received over CAN
68
Notes
69
