16
www.seuservice.com
INSTALLING THE BILLBOARD
To perform work safely and securely, be sure to prepare a step which is in a
secure and stable condition. Performing work without using the step can cause
violent falling down accidents.
The Billboard is extremely heavy, weighing approximately 36kg. When installing
it, be sure to use plural workers. Performing work by one person can cause an
accident.
FIG. 6. 3 a
Mount the BILLBOARD over the
cabinet. When performing work, be
sure to use 3 or more workers.
Take out 3 Truss Screws to open the
BILLBOARD LID.
TRUSS SCREW (3) black
M4 X 8
BILLBOARD LID
For performing work,
use 3 or more workers.
1
2
To Next Page
