Sega LINDBERGH RED User Manual

LINDBERGH SPECIFICATIONS
2
7
Terminal
No.
Signal
Name
Terminal
No.
Signal
Name
1 +3.3V 13 +3.3V
2 +3.3V 14 N.C
3 GND 15 GND
4 +5V 16 PS_ON#
5 GND 17 GND
6 +5V 18 GND
7 GND 19 GND
8 PWR_ON 20 NC
9 +5SB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 GND
(1) Power Connector 1
Terminal
No.
Signal
Name
Terminal
No.
Signal
Name
1 +12V 10 GND
2 +12V 11 GND
3 +5V 12 GND
4 +12V 13 GND
5 +5V 14 GND
6 +12V 15 GND
7 +5V 16 GND
8 +12V 17 GND
9
3.3VRS(SENCE)
18 +3.3V
(2) Power Connector 2
Terminal
No.
Signal
Name
1 +12V
2 +12V
3 +5V
4 +5V
5 GND
6 GND
(3) DVD DRIVE Power Connector
Terminal
No.
Signal
Name
1 DCD
2 RXD
3 TXD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
(14) Serial port 2 (RS232C)
(15) Serial port 1 (RS232C)

Sega LINDBERGH RED Specifications

General

Brand	Sega
Model	LINDBERGH RED
Category	Arcade Game Machines
Language	English
