105
PARTS LIST
19
15 ASSY AC UNIT (RD-1540UK) (D-1/1)
1
2
3
101 102
103
107
109
202
ITEM NO PART NUMBER DESCRIPTION QTY
****1 RD-1541UK AC BRKT 1
****2 TFF-0402UK CONN COVER 1
****3 LB1096 STICKER PROTECTIVE EARTH 1
****101 EP1302 EUROSOCKET FUSED 10A 250VAC 1
****102 514-5078-5000 FUSE 5X20 CERAMIC SB 5000mA 2
****103 SW1109 SWITCH ROCKER 250V AC 1
****104 EP1418 FILTER EPCOS 16A RS496-4778 1
****107 EP1391 COUPLER INLINE LAN RJ45 1
****108 310-5029-D508 HEAT SHRINK SLEEVING 50.8DIA 4
****109 LB1126-5-250 FUSE LABEL 5A 250V 1
****201 000-P00308-W M3X8 MSCR PAN W/FS PAS 2
****202 050-F00400 M4 NUT FLG SER PAS 4
****301 TFF-60001UK WH AC IN 1
