LAMPS AND LIGHTING
13
83
13-4 WOOFER PLATE LED LIGHTING
1
Remove the (4) xings and washers from around the circumfrance of the WOOFER PLATE.
2
Remove the WOOFER PLATE and locate the ASSY WOOFER LED
Remove the (4) xings
and washers
Woofer Plate
Assy Woofer LED
The WOOFER PLATE at the rear of the ASSY SEAT is actively illuminated. To check the functionality or to replace the LED PCB, follow the
steps below.
MAKE SURE THAT THE MAIN SUPPLY VOLTAGE TO THE MACHINE IS SWITCHED
OFF BEFORE ATTEMPTING TO CARRY OUT THIS WORK
