Sega Showdown - Monitor Adjustment Method

66
GRAPHICS DISPLAY
11
11-3 ADJUSTMENT METHOD
Alladjustmentvaluesaresetaccuratelyatthetimeofshippingfromthe
factory.Donotreadjustthesevaluesneedlesslyorapplyadjustmentsnot
speciedinthismanual.Thedisplaymaynotappearproperlyifthevaluesare
incorrect.
CONTROL - ADJUSTMENT PROCEDURE
This sections explains basic control procedures for making adjustments using the buttons on
the 'Monitor Adjustment Board'
This Adjustment Board, and the
Monitor Power Supply are located
behind the Rear Door.
11-3 Fig. 01
Power Supply
LCD Driver Bd
42” LCD Panel
LCD Controller PCB
