2P LINK 3P LINK
4P LINK
FIG. 20. 2 b Connecting method of the communication cable
Arrange the interconnected game machines. Keep a space between the game machines as wide as
possible.
Make the adjusters of all the game machines come into contact with the oor.
Connect the power cords and the earth wires.
10
9
11
Note: Actual Units differ from Image.
