Interface type
The parallel interface or the serial interface is selected. When this function is executed, the
printer is initialized. See "Connecting the computer" on page 12 for correct selection and
connection of the interface cable.
Parity bit (serial interface)
This function selects the appropriate parity bit in the transmission data frame.
Data length (serial interface)
This function selects the appropriate data length.
Stop bit (serial interface)
This function selects the appropriate number of stop bits.
47
5. Extended setup options (30-33)
33 STOP BIT
STOP BIT: 1 BIT
STOP BIT: 2 BIT
32 DATA LENGTH
LENGTH: 8 BITS
LENGTH: 7 BITS
30 INTERFACE
I/F: PARALLEL
I/F: SERIAL
I/F: AUTO
31 PARITY BIT
PARITY: NONE
PARITY: ODD
PARITY: EVEN
.................... Parallel and serial interface are switched
automatically.
