87
ITEM Mode Code & Hexadecimal n: (Hex.) = selection
[33] Bar code type Header n n n: 00=Industrial 2/5, n: 07=Code 128,
1B, 7C, 60, 02, 00, 6E, n
01=Interleave 2/5, 08=EAN 8,
02=Matrix 2/5, 09=EAN 13,
03=Codabar, 0A=UPC-A,
04=Code 11, 0B=UPC-E,
05=Code 39, 0C=Postnet
06=Code 93, 0D=Element
[34] Bar code size Header
o n n: 00=1 n: 02=2
1B, 7C, 60, 02, 00, 6F, n 01=1.5 03=2.5
[35] Interface Header a n n: 00=Parallel,
1B, 7C, 60, 02, 00, 61, n 01=Serial (RS-232C or RS-422 with optional I/F).
02=Auto
Header a 01 a1 a2 a3 a4 a5
1B, 7C, 60, 07, 00, 61, 01, a1, a2, a3, a4, a5
a1: Parity bit a1: 00=None, a1:02=Even.
01=Odd,
a2: Data length a2: 00=8 bits,
01=7 bits.
a3: Stop bit a3: 00=1 bit,
01=2 bits.
a4: Protocol a4: 00=DTR, a4: 02=X-ON/X-OFF (II),
01=X-ON/X-OFF (I), 03=ETX/ACK
a5: Baud rate a5: 00=1200 Baud, a5: 02=4800 Baud,
01=2400 Baud, 03=9600 Baud
[36] Serial error Header b n n: 00=Print "*",
1B, 7C, 60, 02, 00, 62, n 01=Ignore.
[37] Buffer size Header c n n: 00=128 bytes,
1B, 7C, 60, 02, 00, 63, n 01=Maximum.
[38] CSF option Header j n
n: 00=Not installed, n: 02=Double bin.
1B, 7C, 60, 02, 00, 6A, n 01=Single bin,
[39] Factory setting Header E n
n: FF=Yes.
1B, 7C, 60, 02, 00, 45, n
[40] Save setup Header Y n n: 00=Current, n: 02=MEM2,
1B, 7C, 60, 02, 00, 59, n 01=MEM1, 03=MEM3.
[41] LF SPEED Header Z n
n: 00=Normal Speed
1B, 7C, 60, 02, 00, 5A, n
01=Half Speed
[42] CTS, DSR, CD Header d n1 n2 n3 n1: CTS setting
Setting 1B, 7C, 60, 04, 00, 64, n n1=00 CTS Disable
(Serial) n1=01 CTS Enable
n2: DSR setting
n2=00 DSR Disable
n2=01 DSR Enable
n3: CD setting
n3=00 CD Disable
n3=01 CD Enable
[43] ERROR Status Header x n n: 00=ERROR/PE SIGNAL Valid
(Parallel) 1B, 7C, 60, 02, 00, 78, n 01=ERROR/PE Signal invalid
[44] Invert LCD Display Header y n n: 00=Normal LCD Display
1B, 7C, 60, 02, 00, 79, n 01=Invert LCD Display
[45] Energy Star mode Header z n
n: 00=Sleep mode valid
1B, 7C, 60, 02, 00, 7A, n 01=Sleep mode invalid
[46] Reset SW Look Header F n
n: 00=Reset SW is valid in ONLINE
1B, 7C, 60, 02, 00, 46, n 01=Reset SW is invalid in ONLINE
B. Control code summary (Setup options)
