-52-
Rolesofsensors
SensorS1:Locatedatthecardhopperanddetectsthatcardshavebeenset.
SensorS2:Locatedatthecardfeedingportanddetectsthatcardfeedinghasstarted.
SensorS3:Locatedatthereaderandreadsdata.
SensorS4:Locatedatthecardejectoranddetectsthatcardshavebeenejected.
DFsensor:LocatedbetweenS1andS2anddetectsdouble-feeding.
Coveropen:Detectswhetherthetopcoverisopenornot.
Sensorposition
S1
S2 S3 S4
Hopper
Paper feeding roller
DF sensor
Reader
Direction of card feeding
Cover open
10-N SR-305CompatibleCommand
[Explanation]
TheSR-305(SR-305S)typeisequippedwithdatatransfermodesofA,B,C,D,E,F,GandH,which
arealsoavailableforthisdevice.
Fordetails,refertotheSR-305operationmanual.
1
2
10.DataTransferMode
