ATSEL HMI User Manual
TC word DDD 127 0
DM word DDDDD 32767 0
Fins
Register Name bit/word Address format Max. address Mini. address
CIO_bit bit dddd.DD 6143.15 0.0
WR_bit bit ddd.DD 199.15 0.0
HR_bit bit dddd.DD 1535.15 0.0
AR_bit bit ddd.DD 959.15 448.0
DM_bit bit ddddd.DD 32767.15 0.0
CIO word DDDD 6143 0
WR word DDD 199 0
HR word DDDD 1535 0
AR word DDD 959 448
TC word DDD 127 0
DM word DDDDD 32767 0
7. Address searching function
Click the search function of edition or shortcut key crtl+F then the address search
menu is popped up which can search the bit or word of the internal address and external
connection address, or the current scene and all the scenes, and supports the address
replacement at the same time.
Example
1. HMI’s communication parameters setting: set communication port--- mode
selection--PPI
