ATSEL HMI User Manual
4. Flow block
Add expand flow block at advanced components and set the corresponding address
for it.
5. Dynamic rectangle, Dynamic circle
In the Object components, add dynamic rectangle or dynamic circle and set the
corresponding address.
Dynamic rectangle, for example, the data type is 16-bit integer, and the address is
Dynamic circle, for example, the data type is 16-bit integer, and the address is set as
LW1. Then the value of LW1 is the X coordinate of the center of the circle. The value
of LW2 is the Y coordinate of the center of the circle, and the value of LW3 is the
radius of the circle.
Recipe Function
Function introduction
In manufacturing field, recipe describes proportion relation of different recipes, it's
the gather of some variables corresponding parameters setting value during production
process.
For example, a bread factory produces bread, there will be a basic ingredient recipe,
this recipe will list all ingredient lists that used for producing bread (for example
water,flour, sugar, egg, sesame oil etc.)Besides, also list all choosable ingredient lists (for
example fruits, kernel, chocolate chips etc.) These choosable ingredient can be added to
basic recipe to produce various breads. For example,sweet cake will use more
sugars,while low sugar cake will use less sugar. Here, we call the ingredient proportion
relation as recipe.
In ATSEL recipe editor function, one group recipe is one proportion relation. In the
table of editor, customers can match proportion relation among ingredients visually. Click
"Recipe Setting" of tool menu, then you can see recipe configuration dialog box, please
check as below:
1. Create a recipe group and name as bread.
2. Add the ingredients number of bread that is recipe length is 5.
3. Modify ingredients name and matched variable address.
4. Click save recipe and exit.
