ATSEL HMI User Manual
Update program by U DISK
Function
Using USB disk can update HMI's program and firmware version, at the same time, it
can also download the historical data of HMI.
Example
1. Click the tool to pop the drop-down menu and select U disk update.
2. Pop up the U disk update window to update the configuration and firmware of the
current project, and update the three files to the U disk. Mode of operation: choose the
firmware and click the "..." on the right, select save path and store it in the U disk. Click
confirm. Check the configuration again, click on the right "..." select save path and store it
in the U disk. Click confirm.
Note: firmware is the version of the upper computer software. It is recommended to
save it into the U disk to ensure that the version matches the configuration. U disk max.
supports up to 8 different configuration projects. A project needs to modify the
engineering name if it needs multiple configurations and adjust it in the "file name please"
during updating by U disk. The configuration file is required to be placed in the U disk.
3. After the storage is finished, there are three files in the U disk:
