Selec SP112 Series

8
ATSEL HMI User Manual
5. Panasonic Fp series
Register Name bit/word Address format Max. address Mini. address
X bit OOO 377 0
Y bit OOO 377 0
R bit DDDD 7679 0
T bit DDD 4095 0
C bit DDDD 8255 8000
L bit DDD 255 0
DT word DDDDD 99999 0
LD word DDDDD 99999 0
FL word DDDDD 99999 0
SV word DDDD 9999 0
EV word DDDD 9999 0
WX word DDDD 9999 0
WY word DDDD 9999 0
WR word DDDD 9999 0
WL word DDDD 9999 0
IX word D 13 0
IY word D 13 0
ID word D 32 0
6. Omron CP1H
Register Name bit/word Address format Max. address Mini. address
CIO_bit bit dddd.DD 6143.15 0.0
LR_bit bit ddd.DD 199.15 0.0
HR_bit bit dddd.DD 1535.15 0.0
AR_bit bit ddd.DD 959.15 448.0
DM_bit bit ddddd.DD 32767.15 0.0
CIO word DDDD 6143 0
LR word DDD 199 0
HR word DDDD 1535 0
AR word DDD 959 448
