ATSEL HMI User Manual
4.
Mitsubishi FX series
Fx2N
Register name bit/word Address format Max. address Mini. address
X bit OOO 377 0
Y bit OOO 377 0
M bit DDDD 3071 0
S bit DDD 999 0
SM bit DDDD 8255 8000
T bit DDD 255 0
C bit DDD 255 0
D word DDDD 7999 0
SD word DDDD 8255 8000
TV word DDD 255 0
CV word DDD 199 0
32CV word DDD 255 200
Fx3U
Register Name bit/word Address format Max. address Mini. address
X bit OOO 377 0
Y bit OOO 377 0
M bit DDDD 7679 0
S bit DDD 4095 0
SM bit DDDD 8255 8000
T bit DDD 255 0
C bit DDD 255 0
D word DDDD 7999 0
SD word DDDD 8255 8000
TV word DDD 255 0
CV word DDD 199 0
32CV word DDD 255 200
