SELFSAT H22dCSS+ Series User Manual

10
2) How to connect the cable to the antenna and the STB?
dCSS output is only used for connection to dCSS compatible STB.
TV
dCSS 1
TV
dCSS 2
TV
dCSS 5
dCSS Cong : Manaul
IF Channel = CH 1
dCSS Cong : Manaul
IF Channel = CH 2
dCSS Cong : Manaul
IF Channel = CH 5
TV
dCSS 3
dCSS Cong : Manaul
IF Channel = CH 3
IN
OUT
OUT
IN
OUT
OUT
IN
OUT
OUT
TV
dCSS 4
dCSS Cong : Manaul
IF Channel = CH 4
IN
OUT
OUT
TV
dCSS 6
dCSS Cong : Manaul
IF Channel = CH 6
IN
OUT
OUT
IN
OUT
OUT
TV
dCSS 16/24
dCSS Cong : Manaul
IF Channel = CH 16/24
Note
For multiple use of dCSS, splitter(s) is required and splitter is not included in the package.
Note
Each dCSS STB needs to set up different IF channel and center frequency from others.
