4
Contenu de la boite
Corps de l’Antenne
Equerre de Support
Support Principal
Support de Fenêtre A
Support de Fenêtre B
Support de Fixation A
Support de Fixation B
Clé à Boulon
Boussole
A1
B1
B2
B3
B4
B5
B6
C1
C2
A1
B1
B2
B3
B4
B5 B6
C3C2
S1 S3S2 S4 S5
N1
S6
Ecrou à Collet carré M6 (×7)
Vis M4x10 SEMS2 (×4)
Ancrage Hexagonal M6x18 SEMS2 (×3)
Ancrage Hexagonal M6x50 SEMS2 (×1)
Vis à Tête Bombée à Collet Carré M6x30 (×1)
Vis à Tête Bombée à Collet Carré M6x50 (×3)
Boulon en U M6x85 (×2)
N1
S1
S2
S3
S4
S5
S6
