3) Satellite searching and fixing the antenna
LNB Setting Menu
LNB TYPE : Unicable 2
LNB Local : 9750/10600
IF Channel : CH 1
Center Freq. : 1210
Once all connected, turn on the TV and the STB.
Select the antenna / LNB setting menu on your STB.
Setting of dCSS compatible STB
Select the LNB setting menu on your dCSS STB.
Set LNB type to dCSS(Unicable2 or JESS) setting and confirm the IF channel and the center
frequency as below.
Since the IF channel applied to the H22dCSS16+ model and the H22dCSS24+ model is different,
check the model you have and apply it correctly by referring to the table below.
UB Index
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1210
1420
1680
2040
985
1050
1115
1275
1340
1485
1550
1615
1745
1810
1875
1940
X
X
X
X
X
X
X
X
1210
1420
1680
2040
1005
1050
1095
1140
1260
1305
1350
1475
1520
1565
1610
1725
1770
1815
1860
1905
1950
1995
2085
2130
dCSS IF Frequency List
H22dCSS16+ (MHz) H22dCSS24+ (MHz)
