3. Operating Instruction
3-1. Connection Diagram
Use the black color controller cable to connect between the controller and
antenna.
The controller cable looks similar to the antenna cable but you can distinguish
them by the color and labeling.
Portable use
Attach 4 Base Pads to the bottom plate
Adaptor or Cigarette light adaptor
Receiver cable
(Grey color)
Controller cable
C ontroller
C ontroller
(Black color)
CONTROLLER
MAIN UNIT
RECEIVER
TV
To Next Page
