3-3. Quick Reference
When you move SNIPE, the at dish of the antenna must be be in the Home
position.
WARNING
Purchase Power Adapter separately from us, or if you purchase it on your
own, purchase ONLY 18V / 3.3A which is certied.
NOTE
SNIPE will be automatically folded back to HOME position if the vehicle
moves faster than 10km/h, when the reception of GPS is stable.
NOTE
Car Mounting Instruction will be provided separately.
NOTE
Setting
&
Connecting
Take out the antenna from carrying case, and place it on the at ground(or
mount it on the top of the camper) facing South & no obstacle.
1.
One end of the controller cable connect to "controller" port of the main unit
of the antenna.
The other end of the controller cable connect to the port of the controller.
a.
b.
Connect the left port of the antenna, which located at the rear of the main
unit, to the controller using controller cable.
2.
If you use the power source from a car or caravan etc, use the cigarette
lighter adaptor to connect the power to controller.
Otherwise use a suitable 12 Volt DC adaptor to connect the power to
controller.
a.
b.
Connect the power cable to controller .3.
Connect between the right port of the antenna, which located at the rear of
the main unit, to the receiver using receiver cable.
4.
Operating
(Searching the satellite)
Switch on with the “Power switch” button on the top of the controller.
Upon power on, all LED will ash twice.
Wait until “HOME State” light & one “Satellite LED” light, which you set
previously or the rst satellite in the controller (Turksat), remain solid on.
Select the desired satellite using the “UP/DOWN” buttons, then press the
“OK” button to select.
The satellite LED light will start to ash, wait until it stays solid on.
When the satellite LED light stays solid on, the selceted satellite has been
located and a signal can be seen on the satellite TV.
1.
2.
3.
4.
5.
6.
Classication Description
