13. Electrical Current and Tool Requirements
Disintegrator - TABLE 1
DISINTEGRATOR
FULL LOAD CURRENT THREE PHASE POWER
Model # / HP
208V
230V
460V
575V
1012, 1012/5 @ 10 HP
30.8
26.8
13.4
10.7
1012, 1012/5 @ 15 HP
44.2
40.0
20.0
16.0
22 @ 20 HP
55.2
50.0
25.0
20.5
22, 23 @ 25 HP
70.7
64.0
32.0
25.6
22, 23 @30 HP
87.0
75.5
38.0
30.2
23 @ 40 HP
118.0
106.0
53.0
42.0
Fan - TABLE 2
FAN UNIT
Model # / HP
SINGLE PHASE
115V
230V
F071B - 3/4 HP
9.6
4.8
F-034 - 3/4 HP
9.6
4.8
3 - PHASE
460V
230V
F-112 - 1½ HP
4.2
2.1
TOOL REQUIREMENT – TABLE 3
TORQUE WRENCH
ALLEN HEAD
OPEN END
MODEL
BED
KNIVES
Hex Bit Socket
TORQUE
SETTING
ROTOR
KNIVES
Socket
TORQUE
SETTING
BED KNIFE
ADJUSTMENT
MOTOR
ADJUSTMENT
BOLT
HOPPER
BELT
GUARD
1012
5/16
45 Ft.
Lbs.
9/16
50 Ft. Lbs.
1/8
15/16
9/16
7/16
22
1/2
175 Ft.
Lbs.
15/16
195 Ft.
Lbs.
3/16
15/16
3/4
7/16
23
5/16
45 Ft.
Lbs.
15/16
190 Ft.
Lbs.
3/16
15/16
3/4
7/16
BOLT SIZES – TABLE 4
MODEL
BED
ROTOR
1012
3/8-16 x 2
3/8 – 24 x 1-1/2
22
5/8-11” x 2 1/2
5/8 – 18 x 1-1/2
23
3/8–16 x 2 1/2
5/8 – 18 x 1-1/12
NOTE: .005 inch feeler gauge required for knife gap setting.
Rear bed knife adjustment bolts have square heads. A short stamped out open-end wrench required.
