1.4.3. Pedestal Installation
Install the Pedestal
Now you are ready to install the Pedestal Unit. Carefully place the Pedestal Unit over the conduit and wires.
• Place the Pedestal Unit on the Anchor Plate such that the bolt holes are aligned.
• Ensure that the electric wires can be easily accessed through the access panel provided in the
Pedestal’s top section.
• Please ensure that access panel is to your right, when seen from the front end.
Anchor Bolts and Leveling Screws
Installation Manuals Series 7 / 7 Plus EV Charging Station - 1
Copyright ©2021 SemaConnect, Inc. All rights reserved. Page 14 of 26
