pg. 10
!
Anchor Bolts and Leveling Screws
First insert anchor bolts and secure with one or two turns, but do not tighten.
Note: The leveling screws that can be found on four sides are used to adjust for plumb.
!
!
!
!
!
!
Ensure Pedestal is Plumb
Adjust leveling screws to make pedestal plumb (check with Level
at two points separated by 90 degrees).
!
Tighten the Anchor Bolts
Gradually tighten anchor bolts to secure the Pedestal Unit to the
Anchor Plate. Re-check for plumb.
