SemaConnect ChargePro 620 - Specifications

!
pg. 4
!
Specifications
Power Specs!
AC Power Source!
208/240V, center grounded, 60Hz supply
3-wire; Phase A, Phase B, ground (no neutral)!
Power to Electric Vehicle!
30A maximum, 7.2kW@240VAC!
Branch Circuit Protector!
2-pole, common trip, circuit breaker
Breaker rating125% of load (40A for 30A load)!
Vehicle-to-Charger Connection!
SAEJ1772 EV Connector via 18 ft Cable (supplied)!
Energy Metering Accuracy!
1% at 5 min intervals, 0.5% accuracy (optional)!
Time-of-Use Metering!
Charger support provided!
Standby Power!
5W typical !
Safety Specs!
Personnel Protection System!
Charging Circuit Interrupting Device (CCID)
Trip Threshold 5 mA, CCID5 per UL2231-2
!
Automatic³Unplug´Detection!
Charger output voltage terminated
Remote notification via SMS or email(owner configured)!
Codes and Standards Compliance!
Listed to UL2231-1,-2 and UL2594
NEC Article 625 compliant!
Network Specs!
Local Area Network!
2.4GHz 802.15.4 dynamic mesh network!
Wide Area Network!
Commercial CDMA or GPRS cellular network!
Network Communication Protocol!
TCP/IP !
Network Security!
128-bit AES Encryption!
Maximum Charging Station per LAN!
128!
Smart Card Reader!
ISO14443 compliant!
Charger Status Indicating Displays!
LED Array!
270 degree visibility, multi-color visual status indication!
LCD Screen!
2 lines, 16 characters per line, backlit!
Environmental Specs!
Outdoor Rated!
NEMA 3 per NEMA 250-1997, IP44 per IEC 60529!
Operating H umidity !
Up to 95% non-condensing!
Operating Temperature!
-30 degree C to +50 degree C ambient!
Other S pecs!
Surge Protection!
6kV@3,000A per UL 2231-2,Extraprotection optional!
EMC Compliance!
FCC Part15 Class A!
Dimensions !
20 in high x 6 in wide x 6 in deep!
