3) Install the Wall/Pole Mount Bracket
Prepare the Wall/Pole Mount Bracket
First, prepare the wall bracket to be bolted on to the pole.
Firmly attach the Wall/Pole Mount Bracket Plate to the
Wall/Pole Mount Bracket Post using the Wall/Pole Mount
Post screws (3ea).
Make sure that the Post is securely attached to the
Wall/Pole Mount Plate.
!
Strap the Bracket to the Pole
Now place the Wall/Pole Mount Bracket against the pole
and secure it with at least 3 straps as illustrated.
Place a Level alongside the Wall/Pole Mount Bracket, to
ensure the assembly is in an upright position.
Now, fasten the straps to ensure that the bracket is
secure.
Pass the Wires through the Bracket
Run the wires through the Wall/Pole
Bracket and Post.
!
