2.1.1 Boot
The bootloader is the first piece of software executed after power-on reset, and is located at the beginning of flash memory.
The detailed description in AN1200.57 LR1110 Program Memory Update applies to all LR11xx devices.
Two main tasks are assigned to the bootloader:
• The first task checks if a valid firmware is loaded before jumping there.
• The second task loads a firmware: it receives encrypted chunks of data sent through the SPI and performs an on-the-fly
decryption before writing data in flash.
Figure 2-2: Bootloader
2.1.2 Standby
This is the default mode of the LR1121. It is the return state from all other modes (except for specific fall-back options), and
the mode from which transitions to other modes are possible. All commands to configure the device should be issued in
this mode.
Two clocks are available: either the internal 32MHz RC oscillator (Standby RC mode), or an external 32MHz crystal/TCXO
(Standby Xosc mode). The RC clock is used by default for all automatic mode transitions. The crystal/TCXO clock allows
faster transitions to other modes at the expense of a higher power consumption.
2.1.2.1 SetStandby
Command SetStandby(...) sets the device in standby mode with the chosen 32MHz oscillator.
StdbyConfig selects the oscillator used in standby mode:
• 0x00: Selects internal RC oscillator (Standby RC mode)
• 0x01: Selects external Xtal/TCXO oscillator (Standby Xosc mode)
Table 2-1: SetStandby Command
Byte 0 1 2
Data from Host 0x01 0x1C StdbyConfig
Data to Host Stat1 Stat2 IrqStatus(31:24)
Bootloader
Firmware
Flash
The program starts here, then...
... jumps here!
