5.2 VBAT Measurement

5.2.1 GetVbat

GetVbat(...) command monitors the battery supply voltage, it returns the Vbat voltage as a function of a reference

voltage:

Table 5-3: GetVbat Command

Byte 0 1

Data from Host 0x01 0x19

Data to Host Stat1 Stat2

Table 5-4: GetVbat Response

Byte 0 1

Data from Host 0x00 0x00

Data to Host Stat1 Vbat(7:0)

VBAT V 

5 VBat(7:0)

255

----------------------------------

 

 

1–

 

 

1.35=
