7.2.5 SetRxTxFallbackMode

Command SetRxTxFallbackMode(...) defines what mode the device goes into after a packet transmission or a packet

reception. If an Rx Duty Cycle is started or an AutoRxTx is configured, this mode is not used.

• FallbackMode values:

 0x01: Standby RC mode (default value).

 0x02: Standby Xosc mode.

 0x03: FS mode.

 Other values are RFU.

The fallback mode is also used for an Rx Duty Cycle after the RX_DONE interrupt, or for an AutoRxTx after the RX to TX, or

when the TX to RX sequence is completed.

Table 7-5: SetRxTxFallbackMode Command

Byte 0 1 2

Data from Host 0x02 0x13 FallbackMode

Data to Host Stat1 Stat2 IrqStatus (31:24)
