9.1.4.1. WEBSERVER SECTIONS
The Webserver is divided into pages (sections) representing the various gateway functions:
Status
It is the section that displays the values of Modbus requests in real time.
Setup
This is the section that allows the basic configuration of the device, it also allows you to export or import a
configuration.
Setup Modbus Commands / Tags
It is the section that allows you to add/modify the Modbus commands of the Modbus devices connected to the
gateway.
I/O Mapping
This is the section that allows you to remap the bytes relating to the data coming from the Modbus protocol.
Setup IEC Variables
This is the section that allows you to create IEC variables starting from the acquisitions of Modbus commands.
Setup IEC Dataset
This is the section that allows you to create datasets to be used in Report Control Blocks.
Setup IEC Report Control Block
This is the section that allows you to create Report Control Blocks.
Firmware Update
This is the section that allows you to update the device firmware.
Certificate Setup
This is the section that allows you to manage X509 certificates
Serial Traffic Monitor
It allows to analyse the ModBUS frames of the serials.
Local Time Setup
This allows you to set the device date/time
