9.1.4.3. “SETUP” SECTION
DHCP (ETH) (default: Disabled)
Sets the DHCP client to get an IP address automatically.
STATIC IP (default: 192.168.90.101)
Sets the device static address. Careful not to enter devices with the same IP address into the same network.
STATIC IP MASK (default: 255.255.255.0)
Sets the mask for the IP network.
STATIC GATEWAY (default: 192.168.90.1)
Sets the gateway address.
TCP-IP PORT (default: 502)
Sets the communication port for the Modbus TCP-IP client protocol.
TCP-IP TIMEOUT [ms] (default 512 ms)
Sets the waiting time for a request to be considered in timeout.
PORT #1 MODBUS PROTOCOL (default RTU)
Sets the protocol on the serial between Modbus RTU or Modbus ASCII
PORT #2 MODBUS PROTOCOL (default RTU)
Sets the protocol on the serial between Modbus RTU or Modbus ASCII
PORT #1 BAUDRATE (default: 38400 baud)
Selects the communication speed of the COM #1 serial port
PORT #1 DATA BITS (default: 38400 baud)
Selects the communication speed of the COM #1 serial port
PORT #1 PARITY (default: None)
Sets the parity for the COM #1 serial communication port.
PORT #1 STOP BIT (default: 1)
Sets the number of stop bits for the COM #1 serial communication port.
PORT #1 TIMEOUT [ms]
Sets the wait time before defining fail.
PORT #1 WRITING RETRIES (default: 3)
