Using the receiver
19
Using the receiver
To establish a transmission link, proceed as follows:
1. Switch the receiver on (see next section).
2. Switch the transmitter on (see the instruction manual of the transmitter).
The transmission link is established and the receiver’s RF level display
“RF” reacts.
If you cannot establish a transmission link between transmitter and
receiver:
왘 Make sure that transmitter and receiver are set to the same frequency
bank and to the same channel.
왘 Read the chapter “Synchronizing transmitters with receivers” on
page 42 and, if necessary, the chapter “If a problem occurs ...” on
page 47.
Switching the receiver on/off
To switch the receiver on:
It is vital to observe the notes on frequency selection on page 42.
왘 Briefly press the STANDBY button .
The receiver switches on and the “Receiver Parameters” stan-
dard display appears.
533.875
ew100 G3
20.12
MHz
SET
P
PEAK
-10
0
40
25
10
-20
-30
AF
RF
