Putting the receiver into operation
17
Connecting an amplifier/mixing console
The receiver’s ¼” (6.3 mm) jack socket and XLR-3M socket are
connected in parallel, allowing you to simultaneously connect two devices
(e.g. amplifier, mixing console) to the receiver.
왘 Use a suitable cable to connect the amplifier/mixing console to the
¼” (6.3 mm) jack socket or the XLR-3M socket .
For detailed information on balanced and unbalanced connection,
please refer to the chapter “Connector assignment” on page 53.
