Specifications
52
Type approvals
In compliance with
Approved by
S/N ratio (1 mV, peak deviation) ≥ 110 dBA
THD ≤ 0.9%
AF output voltage
(at peak deviation, 1 kHz AF)
¼” (6.3 mm) jack socket (unbalanced): +12 dBu
XLR socket (balanced): +18 dBu
Adjustment range of audio output level 48 dB, adjustable in steps of 3 dB
+6 dB gain reserve
Overall device
Temperature range –10°C to +55°C
Power supply 12 V
Current consumption 300 mA
Dimensions approx. 190 mm x 212 mm x 43 mm
Weight approx. 980 g
Europe
USA
EMC EN 301489-1/-9
Radio EN 300422-1/-2
Safety EN 60065
47 CFR 15 subpart B
Canada Industry Canada RSS 123
IC: 2099A-G3EM100
